HEXAPOD SYSTEMS

Ultra Compact Hexapod (소형 정밀 헥사포드)
High Load Hexapod (고중량 정밀 헥사포드)
Hexapod for Motion Simulation (6축 모션 시뮬레이션 로봇)

Miniature
Compact
Precise & Small
Simple & Affordable
Medium Size
Micropositioning
Strong & Precision
Heavy Loads
High Precision & Heavy Loads
For Astronomy
Acceleration 800 mm/s²
Acceleration 9.8 m/s² (1 g)
Acceleration 9.8 m/s² (1 g)
Acceleration 6000 mm/s²
Acceleration 7000 mm/s²
Customized Hexapods
Customized Solutions
초소형 헥사포드
Compact Positioning Hexapod

Travel Range : ±18 mm (TxTy) / ±10 ° (RxRy)
DC Motor & Absolute Encoder
Resolution : 0.1 μm
Max. Payload : 5 kg
Clean Room Option

Data Sheet
Manual
Video
3D Drawing
소형 헥사포드
Small Positioning Hexapod

Travel Range : ±5 mm (TxTy) / ±8 ° (RxRy)
DC Motor & Absolute Linear Encoder
Resolution : 0.5 μm
Max. Payload : 5 kg
Clean Room / Vacuum Options

Data Sheet
Manual
Video
3D Drawing
정밀 소형 헥사포드
Precision Positioning Hexapod

Travel Range : ±20 mm (TxTy) / ±10 ° (RxRy)
DC Motor & Rotary Encoder
Resolution : 0.1 μm
Max. Payload : 10 kg
Clean Room / Vacuum / Low Temp. Options

Data Sheet
Manual
Video
3D Drawing
정밀 헥사포드
Simple Positioning Hexapod

Travel Range : ±30 mm (TxTy) / ±11 ° (RxRy)
DC Motor & Rotary Encoder
Resolution : 0.5 μm
Max. Payload : 25 kg
Clean Room Compatibility Option

Data Sheet
Manual
Video
3D Drawing
중형 헥사포드
Medium Size Positioning Hexapod

Travel Range : ±750 mm (TxTy) / ±20 ° (RxRy)
Stepper Motor & Absolute Encoder
Resolution : 0.5 μm
Max. Payload : 25 or 200 kg
Clean Room Compatibility Option

Data Sheet
Manual
Video
3D Drawing
초정밀 헥사포드
Accuracy Positioning Hexapod

Travel Range : ±200 mm (TxTy) / ±20 ° (RxRy)
Stepper Motor & Absolute Linear Encoder
Resolution : 0.1 μm
Max. Payload : 400 kg
Clean Room / Vacuum / Higher Speed Options

Data Sheet
Manual
Video
3D Drawing
대형 헥사포드
Large Size Positioning Hexapod

Travel Range : ±150 mm (TxTy) / ±16 ° (RxRy)
Brushless Motor & Absolute Encoder
Resolution : 5 μm
Max. Payload : 200 kg
Clean Room / Heavier Load Options

Data Sheet
Manual
Video
3D Drawing
고중량 헥사포드
High Load Hexapod

Travel Range : ±75 mm (TxTy) / ±5 ° (RxRy)
Stepper Motor & Absolute Linear Encoder
Resolution : 0.2 μm
Max. Payload : 500 kg
Clean Room / Higher Speed / Load Options

Data Sheet
Manual
Video
3D Drawing
고중량 헥사포드
High Load Positioning Hexapod

Travel Range : ±170 mm (TxTy) / ±10 ° (RxRy)
Stepper Motor & Absolute Linear Encoder
Resolution : 0.1 μm
Max. Payload : 1500 kg
Clean Room / Vacuum / Speed / Load Options

Data Sheet
Manual
Video
3D Drawing
천문관측용 헥사포드
Astronomy Hexapod

Travel Range : ±8 mm (TxTy) / ±1 ° (RxRy)
Brushless Motor & Absolute Encoder
Resolution : 0.1 μm
Max. Payload : 500 kg
Outdoor Compatibility Option

Data Sheet
Manual
Video
3D Drawing
초소형 모션 헥사포드
Compact Motion Hexapod

Travel Range : ±100 mm (TxTy) / ±23 ° (RxRy)
Brushless Motor & Absolute Encoder
Max. Payload : 50 kg
Speed : ± 200 mm/s
Outdoor / Real-Time Trajectory Control Options

Data Sheet
Manual
Video
3D Drawing
소형 모션 헥사포드
Small Motion Hexapod

Linear Travel Range : ± 250 mm
Angular Travel Range : ± 25°
Max. Payload : 100 / 200 kg
Speed : ± 1200 mm/s
Outdoor / Real-Time Trajectory Control Options

Data Sheet
Manual
Video
3D Drawing
중형 모션 헥사포드
Medium Size Motion Hexapod

Linear Travel Range : ± 465 mm
Angular Travel Range : ± 30°
Max. Payload : 500 / 1000 kg
Speed : ± 1000 mm/s
Outdoor / Real-Time Trajectory Control Options

Data Sheet
Manual
Video
3D Drawing
대형 모션 헥사포드
Big Size Motion Hexapod

Linear Travel Range : ± 600 mm
Angular Travel Range : ± 40°
Max. Payload : 2000 kg
Speed : ± 2500 mm/s
Outdoor / Real-Time Trajectory Control Options

Data Sheet
Manual
Video
3D Drawing
초대형 모션 헥사포드
Huge Size Motion Hexapod

Linear Travel Range : ± 800 mm
Angular Travel Range : ± 40°
Max. Payload : 6000 kg
Speed : ± 2000 mm/s
Outdoor / Real-Time Trajectory Control Options

Data Sheet
Manual
Video
3D Drawing
커스텀 : 고진공
Custom : UHV Compatibility

UHV Compatible
ISO5 Clean Room Compatibility
Resolution : 0.1 μm
High Payload : 400 kg
Comprehensive Specific Project Management

Data Sheet
Manual
Video
3D Drawing
커스텀 : 클린룸
Custom : ISO5 Cleanroom

ISO5 Clean Room Compatibility
Resolution : 0.1 µm
High Payload : 1 ton
Stability : 2 µrad/°C/15 hours
Comprehensive Specific Project Management

Data Sheet
Manual
Video
3D Drawing
