SERVO DRIVES

Servo Drives with 100kHz Servo Update Rate (서보 드라이브)
Dual Axis 0.5~6.9kW per Axis (2 Level 100 kHz PWM)
Single Axis with AC 9.5~38kW (3 Level 100 kHz PWM)

100kHz Drive (80V, 6A)
100kHz Drive (80V, 10A)
100kHz Drive (80V, 15A)
100kHz Drive (130V, 10A)
100kHz Drive (350V, 10A)
100kHz Drive (350V, 15A)
100kHz Drive (700V, 10A)
100kHz Drive (700V, 20A)
100kHz Drive (700V, 40A)
DC Input Units
AC Input Units
Motor Side Filters
Encoder Splitter
Sensor Amplifier
100kHz 서보 드라이브
100kHz Servo Drive

Dual Axis, 2 Level 100 kHz PWM
Up to 16 bit / 2.5 MHz Sin/cos 1Vss
Current Nominal / Peak : 4.2 Arms / 6 A
Output Power : 460 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Dual Axis, 2 Level 100 kHz PWM
Up to 16 bit / 2.5 MHz Sin/cos 1Vss
Current Nominal / Peak : 10 Arms / 20 A
Output Power : 1100 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Dual Axis, 2 Level 100 kHz PWM
Up to 16 bit / 2.5 MHz Sin/cos 1Vss
Current Nominal / Peak : 15 Arms / 30 A
Output Power : 1650 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Dual Axis, 2 Level 100 kHz PWM
Up to 16 bit / 2.5 MHz Sin/cos 1Vss
Current Nominal / Peak : 10 Arms / 20 A
Output Power : 1680 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Dual Axis, 2 Level 100 kHz PWM
Up to 16 bit / 2.5 MHz Sin/cos 1Vss
Current Nominal / Peak : 10 Arms / 20 A
Output Power : 4600 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Dual Axis, 2 Level 100 kHz PWM
Up to 16 bit / 2.5 MHz Sin/cos 1Vss
Current Nominal / Peak : 15 Arms / 30 A
Output Power : 6900 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Single Axis, 3 Level 100 kHz PWM
Up to 16 bit / 2.6 MHz Sin/cos 1Vss
Current Nominal / Peak : 10 Arms / 20 A
Output Power : 9550 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Single Axis, 3 Level 100 kHz PWM
Up to 16 bit / 2.6 MHz Sin/cos 1Vss
Current Nominal / Peak : 20 Arms / 40 A
Output Power : 19100 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
100kHz 서보 드라이브
100kHz Servo Drive

Single Axis, 3 Level 100 kHz PWM
Up to 16 bit / 2.6 MHz Sin/cos 1Vss
Current Nominal / Peak : 40 Arms / 80 A
Output Power : 38200 W
EtherCAT 100 Mbps / Tria-Link 200 Mbps

Data Sheet
Manual
Video
3D Drawing
전원 구동 장치
DC Input Units

Input Voltage DC Up to 122VDC
Input Current 30 Arms Max.
Braking Voltage : 57V / 90V / 137.5V
Internal Braking Resistor 6Ω
Status Out, Isolated Switch, 24V on/off, 30mA

Data Sheet
Manual
Video
3D Drawing
전원 구동 장치
AC Input Units

Input Voltage Up to 230VAC or 325VDC
Input Current 22 Arms Max.
Braking Voltage : 57V / 90V / 137.5V / 375V
Internal Braking Resistor 7Ω / 18Ω
Status Out, High-Side Switch, 24V on/off, 30mA

Data Sheet
Manual
Video
3D Drawing
모터 필터
Motor Side Filter

Voltage : 80VDC / 135VDC / 365VDC / 780VDC
Current 15Arms / 10Arms / 40Arms
PWM Frequency 50~100kHz
Dimensions : 83x175x250 or 148x350x419mm
For Highest EMC Requirements

Data Sheet
Manual
Video
3D Drawing
엔코더 분배기
Encoder Splitter

Support :
Analog Sin/cos Encoder with Index
Incremental RS422 & RS422 Fast
Support, But not Send Data :
EnDat, BiSS-B, BiSS-C, Tamagawa & Nikon Protocols

Data Sheet
Manual
Video
3D Drawing
센서 신호 증폭기
Sensor Amplifier

Amplifier for IEPE Sensors
(Integrated Electronics Piezo Electric)
Integrates High-pass & Low-pass Filtering
24V Power Supply is Internally Isolated
AN Option Module Required

Data Sheet
Manual
Video
3D Drawing
